SDIO GPS receiver

1. Adapt SiRF Star III low signal levels and high

   sensitivity acquisition

2. Built-in GPS omni directional antenna

3. Supports 20-channel GPS all-in-view

    tracking accuracy

4. Real time navigation for location based

     service

5. LED to show GPS signal fixed or searching

6. Support all standard model, SP1, SD1 and

    SD4 modes

7. SDIO standard ver. 1.10 and 1.20

8. Support OS: Pocket PC 2002/2003, Win

   CE 5.0, Palm OS4.X, 5.X

Features:

1. Receiver tracking: L1 1575.42MHz, CA code 1.023MHz chip rate

2. Position Horizontal: 20 meters, 2D RMS, (no SA) 5 meters, 2D RMS, (WAAS enabled)velocity:0.1m/sec

3. Time: 1 micro-second synchronized to GPS time

4. Datum: Datum default: WGS-84

5. Acquisition Rate:

6. Hot start:<1 sec, average

7. Warm start:<38 sec., average

8. Cold start: <42 sec.,average

9. Reacquisition: 0.1 sec., average

10. Protocol

       Support NMEA 0183 GGA, GSA, GSV,

         RMC, 9600bp

 Specifications
