WIFI 11G SD card

1. IEEE 802.11b/g compatible

2. Support infrastructure and Ad Hoc Peer to Peer connectivity

3. Internal antenna reduces the card size

4. Security supported WEP, WPA, WPA2

5. LED indicated link and activity status

6. SDIO interface compatible

7. Transmit power, 11b 25.11mW, 11g 12.59mW

8. Support Pocket 2002/2003, Win CE 4.0, Mobile 4.2/5.0

Features:

The SDIO IO 11G Wireless LAN Card is a compact size wireless card for PDA and other mobile computing device. The card is designed in the concept to get friendly with battery. When connected to a WLAN, the card is typically in the listening mode almost the time expect the short period of packet being transmitted and received. That means your battery life will maximized. The card works with a lot of wireless LAN security protocols. Open, 64-bit and 128-bit WEP encryptions are supported.

Standards: IEEE 802.11b/g

Connectors: SDIO

LEDs: Power/ACT: always blue ON for power up / Blue blink for data transferring

Data Rate: 11g:6,9,12,1824,36,48,54(OFDM)

                        Mbps

                    11b: 1,2,5,5,11(DSSS/CCK)Mbps

Frequency Range:2.412 ¡V 2.484 GHz band

Range: Indoors:100meter, Outdoors:300 meter

Dimension: 40mm*24mm*2.1mm

Weight: 3.25g

Power consumption: Transmission: 250 mA(Max)

Approval: FCC/CE

Operation Temperature: 0 to 55 ¢J

Storage temperature: -20 to 70 ¢J

Output power: 11b:25.119mW, 11g:12.589mW

 Specifications
