CCTV for Surveillance System |
|
Features: ● Safe, slim and light ● Hot key design for channel switch to VGA,S-Video, A/V input ● BNC connector In/Out for video looping ● Open page of On-screen Display (OSD) design |
|
|
|
|
|
|
Screen Diagonal |
17"(432mm) diagonal TFTLCD； LVDS. Interface |
19"(480mm) diagonal TFTLCD； LVDS. Interface |
22" (559mm) TFT TFT； LVDS. Interface |
|
View Angle |
Horizontal: R/L : 75/75;Vertical: U/D : 70/65. |
Horizontal: R/L : 75/75;Vertical: U/D : 70/65. |
Horizontal: R/L : 85/85;Vertical: U/D : 80/80. |
|
Response Time (Tr/ Tf) |
Tr：8ms：Tf：8ms. |
Tr：8ms：Tf：8ms. |
Tr：3ms：Tf：7ms. |
|
Display Resolution |
1280x1024(SXGA),1024 x 768 (XGA),800 x 600 (SVGA),640 x 480 (VGA) |
1280x1024(SXGA),1024 x 768 (XGA),800 x 600 (SVGA),640 x 480 (VGA) |
1280x1024(WSXGA),1024 x 768 (XGA),800 x 600 (SVGA),640 x 480 (VGA) |
|
Color Reoslution |
16.2M (8 bits) |
16.2M (8 bits) |
16.2M (8 bits) |
|
Pixel Pitch (mm) |
0.264mm (H) x 0.264mm (V) |
0.294mm (H) x 0.294mm (V) |
0.282mm (H) x 0.282mm (V) |
|
Backlight Unit |
4 CCFL, Replaceable. |
4 CCFL, Replaceable. |
4 CCFL, Replaceable. |
|
Brightness (cd/m2) |
250 nits (option 350 nits for high brightness) |
250 nits (350 nits option for high brightness) |
300 nits (400 nits option for high brightness) |
|
Contrast Ratio |
800:1(Typ) |
800:1 ((Typ) |
1000:1(Typ) |
|
Display Area |
338mm (H) x 270mm (V) |
376mm (H) x 301mm (V) |
473.76mm (H) x 296.1mm (V) |
|
I/O Ports |
12V Jack, VGA, BNC in/out ,S-Video, Audio 2in/2out, Earphone. |
12V Jack, VGA, BNC in/out ,S-Video, Audio 2in/2out, Earphone. |
12V Jack, VGA, BNC in/out ,S-Video, Audio 2in/2out, Earphone. |
|
Signal Input |
RGB Analog |
RGB Analog |
RGB Analog |
|
Plug & Play |
DDC 1 / 2B |
DDC 1 / 2B |
DDC 1 / 2B |
|
Speaker out |
1W * 2, 8omh Stereo |
1W * 2, 8omh Stereo |
1W * 2, 8omh Stereo |
|
Audio-In (Speaker) |
1W * 2 |
1W * 2 |
1W * 2 |
|
User’s Control |
Power on/off；Menu；▲ ▼ ; Volume. +/- ; SOU/AUO |
Power on/off；Menu；▲ ▼ ; Volume. +/- ; SOU/AUO |
Power on/off；Menu；▲ ▼ ; Volume. +/- ; SOU/AUO |
|
Safety certifications |
CE, FCC, VCCI, C-Tick |
CE, FCC, VCCI, C-Tick |
CE, FCC, VCCI, C-Tick |
|
Power Adapter |
DC 12V Power Adaptor,(AC90~264, 50 / 60Hz Universal). |
DC 12V Power Adaptor,(AC90~264, 50 / 60Hz Universal). |
DC 12V Power Adaptor,(AC90~264, 50 / 60Hz Universal). |
|
Power Consumption |
VESA-DPMS；Consumption: 40W Max.；Saving Mode: < 3W. |
VESA-DPMS；Consumption: 40W Max.；Saving Mode: < 3W. |
VESA-DPMS；Consumption: 40W Max.；Saving Mode: < 3W. |
|
Environmental Condition |
Operation Temp: 0~50 deg C；Storage Temp.: -20~60 deg C Humidity: 10~90% |
Operation Temp: 0~50 deg C；Storage Temp.: -20~60 deg C Humidity: 10~90% |
Operation Temp: 0~50 deg C；Storage Temp.: -20~60 deg C Humidity: 10~90% |
|
Option Model |
DVI model (DVI-in)/ TV model (TV / Tuner +AV) |
DVI model (DVI-in)/ TV model (TV /Tuner +AV) |
DVI model (DVI-in)/ TV model (TV / Tuner +AV) |
|
Accessories |
12V 48W Adapter；Power Cord；User’s Manual |
12V 48W Adapter；Power Cord；User’s Manual |
12V 48W Adapter；Power Cord；User’s Manual |
